UL13 Power Limited Circuit Cables Type CL2 Bare Copper Stranded Conductor unshield 150 V 75 degree 8 cores 18 AWG cable

Basic Properties
Place of Origin: Trung Quốc
Brand Name: HWATEK
Certification: UL
Model Number: CL2
Trading Properties
Minimum Order Quantity: 1000
Price: negotiable
Standard Packaging: Cuộn hoặc cuộn
Delivery Time: 4 tuần
Payment Terms: T/t
Supply Ability: 1000km/ tháng
Product Summary
UL13 Power Limited Circuit Cables Type CL2 Bare Copper Stranded Conductor unshield 150 V 75 degree 8 cores 18 AWG cable Product Specifications Construction Conductor Bare copper starned Cross section 18AWG Construction 16/0.254mm Strand Dia. 1.18mm Insulation SR-PVC Nom.Thickness 0.23mm Min...

Product Details

Rated Voltage: 150V
Rated Temperature: 75ºC
Conductor Material: dây đồng trần
Conductor Size: 16/0,254mm
Insulation Material: SR-PVC
Insulation Thickness: 0,23mm
Min Insulation Thickness: 0,2mm
Outer Diameter: 1,70 ± 0,10mm
Jacket Material: PVC
Jacket Thickness: 0.84mm
Min Jacket Thickness: 0.66mm
Cable Outer Diameter: 7,6 ± 0,30mm
Max DC Resistance: 21.4Ω/km
Tensile Strength: ≥10.3MPa
Elongation: ≥100%
Spec: HT2504809
Product Description
UL13 Power Limited Circuit Cables Type CL2 Bare Copper Stranded Conductor unshield 150 V 75 degree 8 cores 18 AWG cable Product Specifications Construction Conductor Bare copper starned Cross section 18AWG Construction 16/0.254mm Strand Dia. 1.18mm Insulation SR-PVC Nom.Thickness 0.23mm Min.Thickness 0.20mm Insulation Dia. 1.70±0.10mm Insulation colour 1.white 2.red 3.green 4.blue 5.yellow 6.brown 7.orange 8.black Filler optional Assembly 8Cx18AWG Jacket PVC Nom.Thickness 0
